D200 mm, Polycarbonate, White, Pure white (RAL9010), Power supply unit external (On/Off), 2350 lm, 19.2 W, 122 lm/W, 4000 K, (0.380,0.377) SDCM≦5, White reflector, Polycarbonate, IP20 | Finger-protected, IK02 | 0.2 J standard, Safety class II, 2 cables 0.15m with connectors 2-pole, Push-in connector 4-pole
D150 mm, Polycarbonate, White, Pure white (RAL9010), Power supply unit with DALI interface external, 1200 lm, 14.9 W, 80 lm/W, 4000 K, (0.380,0.377) SDCM≦5, White reflector perforated without louver, White reflector, Polycarbonate, IP20 | Finger-protected, IK02 | 0.2 J standard, Safety class II, 2 cables 0.15m with connectors 2-pole, Emergency lighting 3 hours duration basic version
D150 mm, Polycarbonate, White, Pure white (RAL9010), Power supply unit with DALI interface external, 1150 lm, 14.9 W, 77 lm/W, 4000 K, (0.380,0.377) SDCM≦5, UGR19, Facetted reflector, Facetted reflector, Polycarbonate, IP20 | Finger-protected, IK02 | 0.2 J standard, Safety class II, 2 cables 0.15m with connectors 2-pole, Emergency lighting 3 hours duration basic version
D200 mm, Polycarbonate, White, Pure white (RAL9010), Power supply unit with DALI interface external, 2250 lm, 20.5 W, 110 lm/W, 4000 K, (0.380,0.377) SDCM≦5, UGR19, Facetted reflector, Facetted reflector, Polycarbonate, IP20/54 | Finger-protected; dust accumulation-protected, splash-proof, IK02 | 0.2 J standard, Safety class II, 2 cables 0.15m with connectors 2-pole
D200 mm, Polycarbonate, White, Pure white (RAL9010), Power supply unit with DALI interface external, 2350 lm, 20.5 W, 116 lm/W, 4000 K, (0.380,0.377) SDCM≦5, White reflector perforated without louver, White reflector, Polycarbonate, IP20/54 | Finger-protected; dust accumulation-protected, splash-proof, IK02 | 0.2 J standard, Safety class II, 2 cables 0.15m with connectors 2-pole
Philips CoreLine Downlight delivers on the CoreLine promise of innovative, easy to use and high-quality recessed downlights. The CoreLine Downlight range is suitable for one-to-one conventional luminaire replacements, with an attractive TCO that helps your customers make the switch to LED. These recessed indoor downlights offer uniform light distribution for use in general lighting and office applications (UGR 19). They also deliver instant energy savings and have a much longer lifetime, creating a solution that’s environmentally friendly and real value-for-money. CoreLine DN142B recessed downlights are easy to install thanks to their standard cut-out size and push-in connectors. An Interact ready option with integrated wireless communications is also available in this family, which can be used with Interact gateways, sensors and software.
Benefits
Energy saving and longer lifetime to reduce overall operating costs
One-to-one replacement makes it easy to switch to LED
Low glare suitable for office applications
Features
Available in two cut-out sizes (150mm and 200mm)
White reflector downlight UGR 25
Aluminum reflector downlight UGR 19
Energy efficient: up to 120 lm/W
Choice of color temperatures: 3000K and 4000K
Choice of drivers; DALI and wireless with Interact ready
Optional emergency lighting versions available
Optional IP54 versions available
Applications
Offices, Indoor general areas, Reception and lounge, Meeting rooms, Corridors
Warning & Safety
Do not apply excessive force to the cable & DC connector, make sure the connector clip is locked before the power is on.
Specifications
Ceiling type
Plaster (board) ceiling
Dimming
PSU: non-DimmablePSD: Dimmable (DALI-broadcasting)WIA: Wireless control, compatible with Interact
Control gear failure rate at median useful life 50.000h
